Admincraft•6d ago

Domain & pl3xmap

Hey so I own an earth server and I use pl3xmap for the online map. Just wondering how can I link my subdomain map.astrosmp.fun to my pl3xmap map. Currently ive configured pl3xmap to connect the map with this link http://play.astrosmp.fun:25566/ I have no idea of how domains work so please guide me

Pl3xMap

Pl3xMap is a minimalistic and lightweight world map viewer for Minecraft servers using the vanilla Minecraft rendering style

38 Replies

Error110•6d ago

@Groovyy do u own the server or you use a shared host

GroovyyOP•6d ago

I have a vps

Error110•6d ago

so you can ssh?

GroovyyOP•6d ago

I have no idea but my server partner can why that

Error110•6d ago

nvm ignore me do you want it to use https or http

GroovyyOP•6d ago

Anything works

Error110•6d ago

ok final question do you have a panel

GroovyyOP•6d ago

I do

Error110•6d ago

ok here how to do - go into you node, allocate then add port 80 and your ip into the node - add that allocation to your main server - in pl3xmap config made the port 80 from 25566 - go into your domain settings and make a new record for map.astrosmp.fun if using cloudflare turn off the proxy setting - once all is done restart earth server any more questions on the steps just ask

GroovyyOP•6d ago

The port that I have rn won't work and which type of record? I'm using namecheap rn

Error110•6d ago

just a A record put your ip into it I mean it works but you would have to keep 25566 on your domain if you do port 80 it will auto show so people can just do http://map.astrosmp.fun and see your cool map O wait do you have a nginx config for the map?

Error110•6d ago

http://map.astrosmp.fun:25566/?world=earth&renderer=vintage_story&zoom=3&x=3104&z=-8972

Pl3xMap

Pl3xMap is a minimalistic and lightweight world map viewer for Minecraft servers using the vanilla Minecraft rendering style

Error110•6d ago

so far so good

GroovyyOP•6d ago

Alright so I'll add the numericip:80 to the A record and it'll work?

Error110•6d ago

no just the ip o wait

GroovyyOP•6d ago

yes it works, I just want to get rid of the port

Error110•6d ago

do you mean the panel

GroovyyOP•6d ago

When I added the ip, it opens my panel when going through map.astrosmp.fun

Error110•6d ago

o do you know how to use ssh? if not I can make a nginx config then you send it to whoever is technical on your server

GroovyyOP•6d ago

Sure nope What will it do btw?

Error110•6d ago

server {
    listen 80;
# change to domain
    server_name map.example.com;

    # change to domain
    if ($host = map.example.com) {
        return 301 https://$host$request_uri;
    }
}

server {
    listen 443 ssl;
    server_name map.geoquestmc.com;
# change to location of your ssl files for your panel.
    ssl_certificate ;
    ssl_certificate_key ;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
# change to port of your plexmap
        proxy_pass http://172.18.0.1:8123;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_cache_bypass $http_upgrade;

        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

server {
    listen 80;
# change to domain
    server_name map.example.com;

    # change to domain
    if ($host = map.example.com) {
        return 301 https://$host$request_uri;
    }
}

server {
    listen 443 ssl;
    server_name map.geoquestmc.com;
# change to location of your ssl files for your panel.
    ssl_certificate ;
    ssl_certificate_key ;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
# change to port of your plexmap
        proxy_pass http://172.18.0.1:8123;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_cache_bypass $http_upgrade;

        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

it checks the domain if its map. it will redirect to the domain of the map this isnt perfect but should do the trick given how your server is currently setup

GroovyyOP•6d ago

Alright, I'll send this to my friend and let you know. I'm assuming this will get rid of the port from the domain I'll lyk if this works

Error110•6d ago

ye it should mk

Tamz•6d ago

gonna try making them use a cloudflare tunnel? would be eaiser tbf 👀

Error110•6d ago

no I was gonna get them setup http nginx then was gonna make them just have there map port 80 then realised they had a panel and went back to nginx config if there tech guy can setup a panel hopfully didnt script it and can do nginx config 🙏

Tamz•6d ago

hmm good hopeful but i think it was a script :yeahyupyupyepyepyupmhmyeah: we shall see soon if not they good if yes, cf tunnel it ngl

Error110•6d ago

na they using namecheap cba that

Tamz•6d ago

oh :SadgePlant: that sucks

Error110•6d ago

worst case i give them each command instruction 😭

Tamz•6d ago

cant they nameserver transfer and be fine? 🙏

Error110•6d ago

ye but doesnt it take like 3h

Tamz•6d ago

24h at times your right

Error110•6d ago

sadge

Tamz•6d ago

very but worth imo

Error110•6d ago

true

GroovyyOP•6d ago

https://map.astrosmp.fun/

Pl3xMap

Pl3xMap is a minimalistic and lightweight world map viewer for Minecraft servers using the vanilla Minecraft rendering style

GroovyyOP•6d ago

!!!

Error110•6d ago

👏 U can close this now I'm guessing
