Homarr•6mo ago

Use Caddy as the reverse proxy

Hi, I've been trying to use my Caddy reverse proxy with Homarr, but I'm encountering a problem. Homarr starts using http://ca7dab43dd9f:7575 (Docker container ID) instead of 127.0.0.1 (localhost). This is my docker-compose.yml file:

services:
  homarr:
    container_name: homarr
    image: ghcr.io/ajnart/homarr:latest
    restart: unless-stopped
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock # Optional, only if you want docker integration
      - ./configs:/app/data/configs
      - ./icons:/app/public/icons
      - ./data:/data
    environment:
      NODE_TLS_REJECT_UNAUTHORIZED: 0
      BASE_URL: homarr.localhost
    ports:
      - 127.0.0.1:7575:7575
    networks:
      - reverse_proxy

networks:
  reverse_proxy:
    external: true

services:
  homarr:
    container_name: homarr
    image: ghcr.io/ajnart/homarr:latest
    restart: unless-stopped
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock # Optional, only if you want docker integration
      - ./configs:/app/data/configs
      - ./icons:/app/public/icons
      - ./data:/data
    environment:
      NODE_TLS_REJECT_UNAUTHORIZED: 0
      BASE_URL: homarr.localhost
    ports:
      - 127.0.0.1:7575:7575
    networks:
      - reverse_proxy

networks:
  reverse_proxy:
    external: true

I have the same exact setup using Homepage (https://github.com/gethomepage/homepage) as my personal dashboard for my homelab, and it's working fine. However, I would prefer to use Homarr because I find it nicer. 🙂 I have seen that Traefik works with Homarr. Will Caddy be supported someday? Do you know what might be wrong with my current setup? Thanks for the support!

GitHub

GitHub - gethomepage/homepage: A highly customizable homepage (or s...

A highly customizable homepage (or startpage / application dashboard) with Docker and service API integrations. - gethomepage/homepage

Solution:

I don't know what to write, and I'm not the best English writter 🙂 I have also done this on localhost, I think to use any domain it only require to change it in the Caddyfile homarr.mydomain.com for example. But I can't test this right now because I don't have any domain....

compose.yaml

Caddyfile

Jump to solution

16 Replies

Cakey Bot•6mo ago

Thank you for submitting a support request. Depending on the volume of requests, our team should get in contact with you shortly.

⚠️ Please include the following details in your post or we may reject your request without further comment: - Log (See https://homarr.dev/docs/community/faq#how-do-i-open-the-console--log) - Operating system (Unraid, TrueNAS, Ubuntu, ...) - Exact Homarr version (eg. 0.15.0, not latest) - Configuration (eg. docker-compose, screenshot or similar. Use ``your-text`` to format) - Other relevant information (eg. your devices, your browser, ...)

❓ Frequently Asked Questions | Homarr documentation

Can I install Homarr on a Raspberry Pi?

Manicraft1001•6mo ago

Hi, the URL you see in the logs is just internal. It will & should not be used outside of the container. Apps don't implement "support for reverse proxies" - they should already work out of the box and your Caddy is likely misconfigured or doesn't forward the requests to Homarr. Have you looked into the proxy log? Any log entries in Homarr? Can you reach Homarr from Caddy?

adrinator8OP•6mo ago

First of all thanks for the explanation! And yes I have the logs, the message was too long so I didn't add it 🙂

{"level":"error","ts":1720465243.4753218,"logger":"http.log.error","msg":"dial tcp: lookup board on 127.0.0.11:53: no such host","request":{"remote_ip":"172.20.0.1","remote_port":"45718","client_ip":"172.20.0.1","proto":"HTTP/2.0","method":"GET","host":"homarr.localhost","uri":"/","headers":{"Sec-Gpc":["1"],"Sec-Fetch-Site":["none"],"Sec-Fetch-User":["?1"],"Cache-Control":["max-age=0"],"Upgrade-Insecure-Requests":["1"],"User-Agent":["Mozilla/5.0 (X11; Linux x86_64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/126.0.0.0 Safari/537.36"],"Sec-Fetch-Mode":["navigate"],"Sec-Ch-Ua":["\"Not/A)Brand\";v=\"8\", \"Chromium\";v=\"126\", \"Brave\";v=\"126\""],"Priority":["u=0, i"],"Accept":["text/html,application/xhtml+xml,application/xml;q=0.9,image/avif,image/webp,image/apng,*/*;q=0.8"],"Sec-Ch-Ua-Platform":["\"Linux\""],"Accept-Language":["en-US,en;q=0.9"],"Sec-Fetch-Dest":["document"],"Accept-Encoding":["gzip, deflate, br, zstd"],"Sec-Ch-Ua-Mobile":["?0"]},"tls":{"resumed":true,"version":772,"cipher_suite":4865,"proto":"h2","server_name":"homarr.localhost"}},"duration":1.247334037,"status":502,"err_id":"12py680zj","err_trace":"reverseproxy.statusError (reverseproxy.go:1269)"}

{"level":"error","ts":1720465243.4753218,"logger":"http.log.error","msg":"dial tcp: lookup board on 127.0.0.11:53: no such host","request":{"remote_ip":"172.20.0.1","remote_port":"45718","client_ip":"172.20.0.1","proto":"HTTP/2.0","method":"GET","host":"homarr.localhost","uri":"/","headers":{"Sec-Gpc":["1"],"Sec-Fetch-Site":["none"],"Sec-Fetch-User":["?1"],"Cache-Control":["max-age=0"],"Upgrade-Insecure-Requests":["1"],"User-Agent":["Mozilla/5.0 (X11; Linux x86_64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/126.0.0.0 Safari/537.36"],"Sec-Fetch-Mode":["navigate"],"Sec-Ch-Ua":["\"Not/A)Brand\";v=\"8\", \"Chromium\";v=\"126\", \"Brave\";v=\"126\""],"Priority":["u=0, i"],"Accept":["text/html,application/xhtml+xml,application/xml;q=0.9,image/avif,image/webp,image/apng,*/*;q=0.8"],"Sec-Ch-Ua-Platform":["\"Linux\""],"Accept-Language":["en-US,en;q=0.9"],"Sec-Fetch-Dest":["document"],"Accept-Encoding":["gzip, deflate, br, zstd"],"Sec-Ch-Ua-Mobile":["?0"]},"tls":{"resumed":true,"version":772,"cipher_suite":4865,"proto":"h2","server_name":"homarr.localhost"}},"duration":1.247334037,"status":502,"err_id":"12py680zj","err_trace":"reverseproxy.statusError (reverseproxy.go:1269)"}

Manicraft1001•6mo ago

"remote_ip":"172.20.0.1","remote_port":"45718" are you sure that you forward the requests to the correct port? By default, we expose to 7575 and you seem to do the same.

adrinator8OP•6mo ago

I have all the other containers with this setup and the only one is not working is this, this is because I thought was problem of how Homarr is starting. I have been looking at the Github repo too. Caddyfile: ... homarr.localhost { reverse_proxy homarr:7575 } ... I don't know what's wrong, I posted this here to see if somebody has the same error.

Manicraft1001•6mo ago

Did you check https://discord.com/channels/972958686051962910/1078691258630950992/1078691258630950992 and https://github.com/ajnart/homarr/issues/987#issuecomment-1567404796 ?

adrinator8OP•6mo ago

OMG, i don't know why but after restarting both containers it's working now... Thanks for your help, if you want I can share the whole setup to help people in the future. You can add it to the https://homarr.dev/docs/advanced/configuration/proxies-and-certificates

🔀 Proxies and Certificates | Homarr documentation

Allowing self-signed certificates

Manicraft1001•6mo ago

Yes, please do share it (contribute it to https://github.com/homarr-labs/documentation ). I'll mark this as resolved

GitHub

GitHub - homarr-labs/documentation

Contribute to homarr-labs/documentation development by creating an account on GitHub.

Solution

adrinator8•6mo ago

compose.yaml

Caddyfile

adrinator8OP•6mo ago

For other people: You only have to put Caddyfile at the same folder as compose.yaml (or docker-compose.yml, both names are accepted). And run docker compose up -d and you are done 🙂 @Manicraft1001 If somebody can contribute this and do a better explanation to the documentation repository would be very nice.

Manicraft1001•6mo ago

Almost nobody in this server is native English speaker. We mostly are from Europe. I'd suggest you to try it anyway - all additions are reviewed by us before they go live. It's likely that simply nobody will pick it up otherwise.

adrinator8OP•6mo ago

Okay, I will try it tomorrow! I've never contributed in any repository. Do I need to clone the documentation repo, make a new branch. Do changes, do pnpm start and check if it's OK and then commit and push. Am I wrong? Tell me and I will do my best.

Manicraft1001•6mo ago

You need to fork (since you don't have permissions to push directly). You can close locally or make small adjustments directly via GitHub. It is recommended to quickly install dependencies using pnpm i and start the app with pnpm start. Then you can navigate to the page to check our your changes. After you're done, submit a PR and we'll give you feedback 🙂

adrinator8OP•6mo ago

Oh true, I forgot the fork 🙂 thanks! I'll be doing this as soon as I can. Good night!

adrinator8OP•6mo ago

I have done the Pull Request adding the Caddy setup to the documentation repository. I hope I've done it well 🙂 Tell me if you need anything more!

Manicraft1001•6mo ago

Thank you, we will review soon
